Starting with SQL Server 2012, AlwaysOn Availability Groups provided group level high availability for any number of databases for multiple secondaries known as ‘replicas’. The secondary replicas allow direct read-only querying or can enforce connections that specify ‘ReadOnly’ as their Application Intent using the new feature called Read-Only routing which can be leveraged to scale out reporting workloads. However, in SQL Server 2012 and 2014 versions this redirection is only concerned with the first secondary replica defined in the priority list and all the read-only connections are routed only to that one replica by design. This restricts the other secondary replicas from participating in the load distribution process and thereby reducing the load balancing capability. This article provides you with the configuration and testing of read-only routing along with configuring a custom SQL Agent job in an attempt to create an improved load balancing effect.

Read-only routing refers to the ability of SQL Server to route incoming read-intent connection requests, which are directed to an availability group listener, to an available readable secondary replica. One of the pre-requisites to support read-only routing is that the availability replicas must be enabled for read access.

Tip: Use the below script to check if Read-Only Routing is already configured in your server

SELECT ag.name as "Availability Group", ar.replica_server_name as "When Primary Replica Is",
rl.routing_priority as "Routing Priority", ar2.replica_server_name as "RO Routed To",
ar.secondary_role_allow_connections_desc, ar2.read_only_routing_url
FROM sys.availability_read_only_routing_lists rl
             INNER JOIN sys.availability_replicas ar on rl.replica_id = ar.replica_id
             INNER JOIN sys.availability_replicas ar2 on rl.read_only_replica_id = ar2.replica_id
             INNER JOIN sys.availability_groups ag on ar.group_id = ag.group_id
ORDER BY ag.name, ar.replica_server_name, rl.routing_priority

To make it easy to understand, in this demo, we will use the below terminology:

  • Availability group named AG
  • Listener named AGLISTEN
  • Replicas SQL01A (primary) and SQL01B(secondary)

NOTE: Read-only routing can support ALLOW_CONNECTIONS property set to READ_ONLY or ALL (Graphically shown below)

0

Once the secondaries are set to readable (Read-Intent only/Yes), the below three steps are required to configure Read-Only Routing –

  1. Define a read-only routing URL
  2. Define a read-only routing List
  3. Update the client’s connection string to specify Application Intent connection property as ‘read-only’

Let’s take a look at the above steps in details.

1.   Configure Read-Only routing URL

A read_only_routing_url is the entry point of an application to connect to a readable secondary. It contains the system address or the port number that identifies the replica when acting as a readable secondary. This is similar to the endpoint URL we specify when configuring database mirroring. For each readable secondary replica that is to support read-only routing, you need to specify this routing URL

For example, define a URL SQL01B, so that when SQL01B is in the secondary role, it can accept read-only connections.

ALTER AVAILABILITY GROUP AG MODIFY REPLICA ON N'SQL01A' WITH (SECONDARY_ROLE (READ_ONLY_ROUTING_URL = N'TCP://SQL01A:1433'))
ALTER AVAILABILITY GROUP AG MODIFY REPLICA ON N'SQL01B' WITH (SECONDARY_ROLE (READ_ONLY_ROUTING_URL = N'TCP://SQL01B:1433'))

Tip: Use THIS code to generate routing URLs for each available secondary replicas to use in the above script




2.   Configure Read-Only routing List

For each replica that will act as primary, we need to define the corresponding secondary replicas that will act as the routing target for read-only workloads. This means that if the replica is acting as a primary, all read-only workloads will be redirected to the replicas in the read-only routing list. For example, when SQL01A is in the primary role, define our routing list to consist of SQL01B which is where read-only connection requests will be routed first and if it is not available or not synchronizing (Only in SQL Server 2012) connections will go to the next server in the list.

ALTER AVAILABILITY GROUP AG MODIFY REPLICA ON N'SQL01A' WITH (PRIMARY_ROLE (READ_ONLY_ROUTING_LIST= ('SQL01B', ‘SQL01A’)));
GO
ALTER AVAILABILITY GROUP AG MODIFY REPLICA ON N'SQL01B' WITH (PRIMARY_ROLE (READ_ONLY_ROUTING_LIST= ('SQL01A', ‘SQL01B’)));

Tip: Alternatively to automate the above process you can use THIS script to dynamically generate the scripts required mentioned in the above tasks

Unfortunately there is no graphical user interface to perform these tasks in SSMS. The read-only routing URL and the routing list can be performed only through Transact-SQL or PowerShell

NOTE: As a best practice it is always recommended to assign the primary replica name at the end of the routing list separated by comma, in the rare event if all of the available secondary replicas are not available.

3.   Update client connection string

Read-only clients must direct their connection requests to this listener, and the client’s connection strings must specify the application intent as “read-only.” That is, they must be read-intent connection requests. This can be seen in the connection string, an example is shown below:

Server=tcp:aglisten,1433;Database=agdb1;IntegratedSecurity=SSPI;
ApplicationIntent=ReadOnly;MultiSubnetFailover=True

Before making client side changes you can confirm this newly configured read-only routing using SQL CMD by specifying application intent option (-K) as shown below

Sqlcmd –S AGLISTEN –E –d AGDB1 –K readonly

1

Load Balancing using Read-Only Routing List

The read-only routing introduced in SQL Server 2012 is used for redirection and offloading the read queries to the secondary replicas instead of primary replica. However, this redirection is only concerned with the first secondary replica defined in the priority list that we define. Since the primary replica strictly traverses the list and looks for the first replica that can serve the connection request. Once found, all subsequent read-only connections are routed to it. For example, in a multiple secondary architecture, all the read intent queries only hit the first secondary replica in the list while other secondaries do not participate in distributing this load. This limits the load balancing capability among other secondary replicas.

To overcome this situation here a workaround that will modify the Read-Only Routing list periodically to let read intent queries to use all the replicas at certain intervals (every 30 seconds in this case), so as to create a load balancing effect. This is only applicable to SQL Servers running 2012 and 2014 versions since starting with SQL Server 2016, Microsoft changed the game by introducing native load-balancing capabilities which we will look into later in the paper

WHILE 1=1
Begin
If (
SELECT ARS.role_desc
FROM SYS.availability_REPLICAs AR
join sys.dm_hadr_availability_REPLICA_states ARS ON AR.REPLICA_id = ARS.REPLICA_id
WHERE AR.REPLICA_server_name = (select @@SERVERNAME)
) = 'PRIMARY' and (select count(*) from sys.availability_read_ONly_routing_lists) > 1
Begin
ALTER AVAILABILITY GROUP [AGDB1]
MODIFY REPLICA ON N'SQL01A' WITH (Primary_Role (READ_ONLY_ROUTING_LIST =('SQL01B','SQL01A')))
ALTER AVAILABILITY GROUP [AGDB1]
MODIFY REPLICA ON N'SQL01B' WITH (Primary_Role (READ_ONLY_ROUTING_LIST =('SQL01A','SQL01B')))
--print 'changing ROR URL in 30 seconds...'
WAITFOR DELAY '00:00:30'
--print 'Changing ROR URL'
--Run every 30 secONds
ALTER AVAILABILITY GROUP [AGDB1]
MODIFY REPLICA ON N'SQL01A' WITH (Primary_Role (READ_ONLY_ROUTING_LIST =('SQL01A','SQL01B')))
ALTER AVAILABILITY GROUP [AGDB1]
MODIFY REPLICA ON N'SQL01B' WITH (Primary_Role (READ_ONLY_ROUTING_LIST =('SQL01B','SQL01A')))

END
WAITFOR DELAY '00:00:30'
End

Note: You can add additional replica details based on the number of secondary replicas configured in your Read-Only Routing

To complete the procedure run the code from above in a new query window in SSMS for testing purposes and once verified you can then use the code to create a SQL agent job in all the replicas. This job needs to be run continuously on each replica. The code will only run from the instance that is in the PRIMARY role.

The verify the Read-Only Routing is rotating correctly run the below script

SELECT ag.name as "Availability Group", ar.replica_server_name as "When Primary Replica Is",
rl.routing_priority as "Routing Priority", ar2.replica_server_name as "RO Routed To"
FROM sys.availability_read_only_routing_lists rl
    INNER JOIN sys.availability_replicas ar on rl.replica_id = ar.replica_id
    INNER JOIN sys.availability_replicas ar2 on rl.read_only_replica_id = ar2.replica_id
    INNER JOIN sys.availability_groups ag on ar.group_id = ag.group_id
ORDER BY ag.name, ar.replica_server_name, rl.routing_priority

4

After 30 seconds, notice that the “RO Routed To” column alternates among the available secondary replicas.

4

As evident from above result, this code modifies Read-Only routing list bringing in a new secondary replica into play periodically to cater for the read intent connections essentially creating a load balancing effect. Load balancing using this technique provides a way to get even more use from server hardware that host secondary’s databases and provide reporting applications with better performance and throughput especially for long and resource intensive queries. Please note that this algorithm is limited but it serves the purpose quite effectively. A similar but much robust algorithm has been built into the native SQL engine starting with SQL Server 2016.

Read Full Post »

If you are familiar with the new feature Read-Only Routing introduced in SQL Server 2012 with AlwaysOn then you should keep this script handy to generate URLs to be used in Read-Only Routing configuration instead of typing down yourself to limit any errors.

Connect to each replica in your AlwaysOn Availability Group and run the below script to get the read_only_routing_url for that replica.
Then copy the URL from the result set and use it when setting up read_only_routing_url. Find more details on that here

PRINT 'Read-only-routing url script v.2012.1.24.1'

PRINT 'This SQL Server instance version is [' + cast(serverproperty('ProductVersion') as varchar(256)) + ']'

IF (ServerProperty('IsClustered') = 1)
BEGIN
    PRINT 'This SQL Server instance is a clustered SQL Server instance.'
END
ELSE
BEGIN
    PRINT 'This SQL Server instance is a stANDard (not clustered) SQL Server instance.'
END

IF (ServerProperty('IsHadrEnabled') = 1)
BEGIN
    PRINT 'This SQL Server instance is enabled for AlwaysOn.'
END
ELSE
BEGIN
    PRINT 'This SQL Server instance is NOT enabled for AlwaysOn.'
END

-- Detect SQL Azure instance.
DECLARE @is_sql_azure bit
SET @is_sql_azure = 0

BEGIN try
    SET @is_sql_azure = 1
    EXEC('DECLARE @i int SET @i = sql_connection_mode()')
    PRINT 'This SQL Server instance is a Sql Azure instance.'
END try
BEGIN catch
    SET @is_sql_azure = 0
    PRINT 'This SQL Server instance is NOT a Sql Azure instance.'
END catch

-- Check that this is SQL 11 or later, otherwise fail fast.
IF (@@microsoftversion / 0x01000000 < 11 or @is_sql_azure > 0)
BEGIN
    PRINT 'This SQL Server instance does not support read-only routing, exiting script.'
END
ELSE
BEGIN -- IF server supports read-only routing

    -- Fetch the dedicated admin connection (dac) port.
    -- Normally it's always port 1434, but to be safe here we fetch it FROM the instance.
    -- We use this later to exclude the admin port FROM read_only_routing_url.
    DECLARE @dac_port int
    DECLARE @reg_value varchar(255)
    EXEC xp_instance_regread
        N'HKEY_LOCAL_MACHINE',
        N'SOFTWARE\Microsoft\Microsoft SQL Server\\MSSQLServer\SuperSocketNetLib\AdminConnection\Tcp',
        N'TcpDynamicPorts',
        @reg_value output

    SET @dac_port = cast(@reg_value as int)

    PRINT 'This SQL Server instance DAC (dedicated admin) port is ' + cast(@dac_port as varchar(255))
    IF (@dac_port = 0)
    BEGIN
        PRINT 'Note a DAC port of zero means the dedicated admin port is not enabled.'
    END

    -- Fetch ListenOnAllIPs value.
    -- IF SET to 1, this means the instance is listening to all IP addresses.
    -- IF SET to 0, this means the instance is listening to specIFic IP addresses.
    DECLARE @listen_all int
    EXEC xp_instance_regread
        N'HKEY_LOCAL_MACHINE',
        N'SOFTWARE\Microsoft\Microsoft SQL Server\\MSSQLServer\SuperSocketNetLib\Tcp',
        N'ListenOnAllIPs',
        @listen_all output

    IF (@listen_all = 1)
    BEGIN
        PRINT 'This SQL Server instance is listening to all IP addresses (default mode).'
    END
    ELSE
    BEGIN
        PRINT 'This SQL Server instance is listening to specIFic IP addresses (ListenOnAllIPs is disabled).'
    END

    -- Check for dynamic port configuration, not recommended with read-only routing.
    DECLARE @tcp_dynamic_ports varchar(255)
    EXEC xp_instance_regread
        N'HKEY_LOCAL_MACHINE',
        N'SOFTWARE\Microsoft\Microsoft SQL Server\\MSSQLServer\SuperSocketNetLib\Tcp\IPAll',
        N'TcpDynamicPorts',
        @tcp_dynamic_ports output

    IF (@tcp_dynamic_ports = '0')
    BEGIN
        PRINT 'This SQL Server instance is listening on a dynamic tcp port, this is NOT A RECOMMENDED CONFIGURATION when using read-only routing, because the instance port can change each time the instance is restarted.'
    END
 ELSE
    BEGIN
        PRINT 'This SQL Server instance is listening on fixed tcp port(s) (it is not configured for dynamic ports), this is a recommended configuration when using read-only routing.'
    END

    -- Calculate the server domain AND instance FQDN.
    -- We use @server_domain later to build the FQDN to the clustered instance.
    DECLARE @instance_fqdn varchar(255)
    DECLARE @server_domain varchar(255)

    -- Get the instance FQDN using the xp_getnetname API
    -- Note all cluster nodes must be in same domain, so this works for calculating cluster FQDN.
    SET @instance_fqdn = ''
		EXEC xp_getnetname @instance_fqdn output, 1

    -- Remove embedded null character at END IF found.
    DECLARE @terminator int
		SET @terminator = charindex(char(0), @instance_fqdn) - 1
			 IF (@terminator > 0)
		BEGIN
			SET @instance_fqdn = substring(@instance_fqdn, 1, @terminator)
		END
     -- Build @server_domain using @instance_fqdn.
		 SET @server_domain = @instance_fqdn
     -- Remove trailing portion to extract domain name.
		 SET @terminator = charindex('.', @server_domain)
    IF (@terminator > 0)
		 BEGIN
			SET @server_domain = substring(@server_domain, @terminator+1, datalength(@server_domain))
		 END
    PRINT 'This SQL Server instance resides in domain ''' +  @server_domain + ''''

    IF (ServerProperty('IsClustered') = 1)
    BEGIN
        -- Fetch machine name, which for a clustered SQL instance returns the network name of the virtual server.
        -- AppEND @server_domain to build the FQDN.
        SET @instance_fqdn = cast(serverproperty('MachineName') as varchar(255)) + '.' + @server_domain
    END

    DECLARE @ror_url varchar(255)
    DECLARE @instance_port int

    SET @ror_url = ''
    -- Get first available port for instance.
    SELECT TOP 1    -- SELECT first matching port
    @instance_port = port
    FROM sys.dm_tcp_listener_states
    WHERE type=0 -- Type 0 = TSQL (to avoid mirroring ENDpoint)
    AND state=0    --  State 0 is online
    AND port <> @dac_port -- Avoid DAC port (admin port)
    AND
    -- Avoid availability GROUP listeners
    ip_address not in (SELECT ip_address FROM sys.availability_GROUP_listener_ip_addresses agls)
    GROUP by port
    ORDER BY port asc  -- Pick first port in ascENDing ORDER

    -- Check IF there are multiple ports AND warn IF this is the case.
    DECLARE @list_of_ports varchar(max)
    SET @list_of_ports = ''

    SELECT
    @list_of_ports = @list_of_ports +
        case datalength(@list_of_ports)
        when 0 then cast(port as varchar(max))
        ELSE ',' +  cast(port as varchar(max))
        END
    FROM sys.dm_tcp_listener_states
    WHERE type=0    --     Type 0 = TSQL (to avoid mirroring ENDpoint)
    AND  state=0    --  State 0 is online
    AND  port <> @dac_port -- Avoid DAC port (admin port)
    AND
    -- Avoid availability GROUP listeners
    ip_address not in (SELECT ip_address FROM sys.availability_GROUP_listener_ip_addresses agls)
    GROUP BY port
    ORDER BY port asc

    PRINT 'This SQL Server instance FQDN (Fully QualIFied Domain Name) is ''' + @instance_fqdn + ''''
    PRINT 'This SQL Server instance port is ' + cast(@instance_port as varchar(10))

    SET @ror_url = 'tcp://' + @instance_fqdn + ':' + cast(@instance_port as varchar(10))

    PRINT '****************************************************************************************************************'
    PRINT 'The read_only_routing_url for this SQL Server instance is ''' + @ror_url + ''''
    PRINT '****************************************************************************************************************'

    -- IF there is more than one instance port (unusual) list them out just in case.
    IF (charindex(',', @list_of_ports) > 0)
    BEGIN
        PRINT 'Note there is more than one instance port, the list of available instance ports for read_only_routing_url is (' + @list_of_ports + ')'
        PRINT 'The above URL just uses the first port in the list, but you can use any of these available ports.'
    END
	END
